Portable Jib Cranes

Unique design allows for easy transportation of jib crane with a fork truck

Empty base models include instructions for proper filling with concrete Base measures 42-3/16″ x 42-3/16″ x 18″H or 36″H and includes built-in fork tubes. Fork tubes are 7-5/8″W x 2-5/8″H usable on 24″ fork centers, for transportation with fork truck. Fixed length I-beam will pivot 360 degrees for complete access. Under I-beam clearance is 10′. Upright vertical column bolts to base. Steel construction with blue painted finish. Units ship knocked down. Not for use as a fork truck attachment.

Portable Jib Crane
Model PDF Under I-Beam
Height		 I-Beam
Length		 I-Beam
Height		 I-Beam
Flange Width		 Base
Height		 Capacity
(lbs)		 Wt.
(lbs)
JIB-CB-25-8-10 120-1/16″ 96″ 6″ 4″ 18″ 250 981
JIB-CB-25-10-10 119-15/16″ 120″ 6″ 4″ 18″ 250 985
JIB-CB-50-8-10 120-1/16″ 96″ 6″ 4″ 18″ 500 982
JIB-CB-50-10-10 120-3/16″ 120″ 10-1/8″ 4″ 36″ 500 1302
JIB-CB-100-8-10 120-3/16″ 96″ 10-1/8″ 4″ 36″ 1000 1193
JIB-CB-18-B Additional Steel Base -18″H- Empty 479
JIB-CB-36-B Additional Steel Base -36″H- Empty 617
Portable Jib w/ Concrete Filled Base
JIB-CB-25-8-10-BC 120-1/16″ 96″ 6″ 4″ 18″ 250 3443
JIB-CB-25-10-10-BC 119-15/16″ 120″ 6″ 4″ 18″ 250 3192
JIB-CB-50-8-10-BC 120-1/16″ 96″ 6″ 4″ 18″ 500 3448
JIB-CB-50-10-10-BC 120-3/16″ 120″ 10-1/8″ 4″ 36″ 500 5749
JIB-CB-100-8-10-BC 120-3/16″ 96″ 10-1/8″ 4″ 36″ 1000 5715

KEY: = Approval Drawing — = Warranty — = Testing Certificate

Additional information

Concrete Base

With Concrete Base, Without Concrete Base
Under I-Beam Height

120-1/16", 250 lbs. Capacity, 119-15/16", 250 lbs. Capacity, 120-1/16", 500 lbs. Capacity
