Sale!

Super Vibratory Screed Online now

Original price was: $4,144.99.Current price is: $299.99.

SKU: US-6599216758958 Categories: , Tags: ,

Description

Super Vibratory Screed

Super Vibratory Screed so you don’t need to break your back for industry leading consolidation

Features of Super Screed

  • High frequency vibrations distributed evenly across entire aluminum screed length to produce smooth, uniform surfaces quickly and easily.
  • Capable of consolidating and condensing concrete with slumps of less than 2″ with up to 14, 000 vibrations per minute to perform 25% faster than competitive screeds on either high or low slump concrete.
  • Powered by highly efficient Honda engines that burn less than 1 gallon (3.8L) in an 8 hour day.
  • Vibrations are distributed through a rotating shaft that oscillates inside durable bearing housings.
  • Use with any forms – metal, wood, screed pipe or concrete block. Capable of checker-boarding from adjacet concrete surfaces.
  • Turnbuckles located along entire length to make it easy to adjust for crowns, valleys or flat surfaces. Adjustments can be made up to 1/4″ per foot and jam nuts lock it firmly in place to meet demanding “F” floor specifications.
  • Light weight aluminum/magnesium frame provides exceptional strength and durability.
  • Bolted construction throughout – no welds to break, no need for special tools. Parts can be easily replaced on the jobsite if necessary.

Available Options

  • Transportation Cart
  • Curb Forming End Adaptors
  • Bridge Parapet Adaptor
  • Hand Winch
  • Extended turnbuckles allow screed to be inverted 1/2″ per ft. (12.7mm/m versus standard 1/4″ (6.4mm).Options

Specification Super Screed

Height

19.5″ (495.3mm)

Width

14.625″ (371.48mm)

Weight
10′ Base Section 5′ Section 2.5′ Section 10′ Section

15lbs per foot

94lbs (42.68kg)

46lbs (20.88kg)

23lbs (10.44kg)

91lbs 41.31kg)

Motor w/Mount

70lbs (31.73kg)

Engine

Honda GX270

Maximum Recommended Span

80′ (24.4m)

Average Peak Vibration

14 000 vpm

Maximum Compaction Depth

12″ (304.8mm)



Spec Sheet



Additional information

Super Vibratory Screed Options

5' Base with Mounting Kit & Engine, 10' Base with Mounting Kit & Engine, 5' Base -No Kit, 10' Base – No Kit, 1' Subsection, 2.5' Subsection, 5' Subsection, 10' Subsection, Mounting Kit, Engine, End adapters, Screed Cart, Double Hand Winch, Carry Handles, Extended Turnbuckles, Bridge Adaptor, Self-Propelled Hydraulic End Section – LH, Self-Propelled Hydraulic End Section – RH
